| 项目 | 描述 |
|---|
| 天线类型 | 室外型外接天线 |
| 可同时在线的用户数量 | ≤256 |
| 每射频最大VAP数量 | 16 |
| 最大发射功率 | - 2.4G：28dBm（组合功率）
- 5G：26dBm（组合功率）
说明
实际发射功率遵照不同国家和地区法规而有所不同。
发射功率支持1dB步长调整，可调范围支持从最大发射功率向下调整至1dBm。 |
| 非重叠频道最大数量 | 2.4 GHz
| 5 GHz
- 802.11a
- 802.11n
- 802.11ac
- 20MHz： 13
- 40MHz： 6
- 80MHz： 3
| 说明
表格中以中国支持的非重叠频道数量为例，不同国家支持的非重叠信道的数量也不相同，具体请参考《国家码&信道顺从表》。 |
| 支持的信道速率 | - 802.11b：1、2、5.5和11Mbit/s
- 802.11a/g：6、9、12、18、24、36、48和54Mbit/s
- 802.11n：6.5 Mbit/s～450Mbit/s
- 802.11ac：6.5 Mbit/s～867Mbit/s
|
| 接收灵敏度（典型值） | 2.4 GHz
802.11b (CCK)- -100 dBm @ 1 Mb/s
- -94 dBm @ 2 Mb/s
- -94 dBm @ 5.5 Mb/s
- -90 dBm @ 11 Mb/s
| 2.4 GHz
802.11g (non-HT20)- -95 dBm @ 6 Mb/s
- -95 dBm @ 9 Mb/s
- -94 dBm @ 12 Mb/s
- -94 dBm @ 18 Mb/s
- -91 dBm @ 24 Mb/s
- -87 dBm @ 36 Mb/s
- -83 dBm @ 48 Mb/s
- -82 dBm @ 54 Mb/s
| 2.4 GHz
802.11n (HT20)- -95 dBm @ MCS0
- -95 dBm @ MCS1
- -94 dBm @ MCS2
- -89 dBm @ MCS3
- -85 dBm @ MCS4
- -82 dBm @ MCS5
- -80 dBm @ MCS6
- -78 dBm @ MCS7
- -93 dBm @ MCS8
- -93 dBm @ MCS9
- -92 dBm @ MCS10
- -87 dBm @ MCS11
- -83 dBm @ MCS12
- -80 dBm @ MCS13
- -78 dBm @ MCS14
- -76 dBm @ MCS15
- -91 dBm @ MCS16
- -91 dBm @ MCS17
- -90 dBm @ MCS18
- -85 dBm @ MCS19
- -81 dBm @ MCS20
- -78 dBm @ MCS21
- -76 dBm @ MCS22
- -74 dBm @ MCS23
| 2.4 GHz
802.11n(HT40)- -92 dBm @ MCS0
- -90 dBm @ MCS1
- -90 dBm @ MCS2
- -85 dBm @ MCS3
- -83 dBm @ MCS4
- -79 dBm @ MCS5
- -78 dBm @ MCS6
- -75 dBm @ MCS7
- -90 dBm @ MCS8
- -88 dBm @ MCS9
- -88 dBm @ MCS10
- -83 dBm @ MCS11
- -81 dBm @ MCS12
- -77 dBm @ MCS13
- -76 dBm @ MCS14
- -73 dBm @ MCS15
- -88 dBm @ MCS16
- -86 dBm @ MCS17
- -86 dBm @ MCS18
- -81 dBm @ MCS19
- -79 dBm @ MCS20
- -75 dBm @ MCS21
- -74 dBm @ MCS22
- -71 dBm @ MCS23
|
5 GHz
802.11a (non-HT20)- -96 dBm @ 6 Mb/s
- -95 dBm @ 9 Mb/s
- -94 dBm @ 12 Mb/s
- -93 dBm @ 18 Mb/s
- -89 dBm @ 24 Mb/s
- -86 dBm @ 36 Mb/s
- -82 dBm @ 48 Mb/s
- -80 dBm @ 54 Mb/s
| 5 GHz
802.11n (HT20)- -95 dBm @ MCS0
- -94 dBm @ MCS1
- -93 dBm @ MCS2
- -88 dBm @ MCS3
- -85 dBm @ MCS4
- -80 dBm @ MCS5
- -79 dBm @ MCS6
- -78 dBm @ MCS7
- -93 dBm @ MCS8
- -92 dBm @ MCS9
- -91 dBm @ MCS10
- -86 dBm @ MCS11
- -83 dBm @ MCS12
- -78 dBm @ MCS13
- -77 dBm @ MCS14
- -76 dBm @ MCS15
- -91 dBm @ MCS16
- -90 dBm @ MCS17
- -89 dBm @ MCS18
- -84 dBm @ MCS19
- -81 dBm @ MCS20
- -76 dBm @ MCS21
- -75 dBm @ MCS22
- -74 dBm @ MCS23
| 5 GHz
802.11n (HT40)- -92 dBm @ MCS0
- -91 dBm @ MCS1
- -90 dBm @ MCS2
- -85 dBm @ MCS3
- -82 dBm @ MCS4
- -78 dBm @ MCS5
- -76 dBm @ MCS6
- -75 dBm @ MCS7
- -90 dBm @ MCS8
- -89 dBm @ MCS9
- -88 dBm @ MCS10
- -83 dBm @ MCS11
- -80 dBm @ MCS12
- -76 dBm @ MCS13
- -74 dBm @ MCS14
- -73 dBm @ MCS15
- -88 dBm @ MCS16
- -87 dBm @ MCS17
- -86 dBm @ MCS18
- -81 dBm @ MCS19
- -78 dBm @ MCS20
- -74 dBm @ MCS21
- -72 dBm @ MCS22
- -71 dBm @ MCS23
| - |
5 GHz
802.11ac (VHT20)- -95 dBm @ MCS0NSS1
- -94 dBm @ MCS1NSS1
- -93 dBm @ MCS2NSS1
- -88 dBm @ MCS3NSS1
- -85 dBm @ MCS4NSS1
- -80 dBm @ MCS5NSS1
- -78 dBm @ MCS6NSS1
- -77 dBm @ MCS7NSS1
- -73 dBm @ MCS8NSS1
- -93 dBm @ MCS0NSS2
- -92 dBm @ MCS1NSS2
- -91 dBm @ MCS2NSS2
- -86 dBm @ MCS3NSS2
- -83 dBm @ MCS4NSS2
- -78 dBm @ MCS5NSS2
- -76 dBm @ MCS6NSS2
- -75 dBm @ MCS7NSS2
- -71 dBm @ MCS8NSS2
- -91 dBm @ MCS0NSS3
- -90 dBm @ MCS1NSS3
- -89 dBm @ MCS2NSS3
- -84 dBm @ MCS3NSS3
- -81 dBm @ MCS4NSS3
- -76 dBm @ MCS5NSS3
- -74 dBm @ MCS6NSS3
- -73 dBm @ MCS7NSS3
- -69 dBm @ MCS8NSS3
- -67 dBm @ MCS9NSS3
| 5 GHz
802.11ac (VHT40)- -92 dBm @ MCS0NSS1
- -92 dBm @ MCS1NSS1
- -89 dBm @ MCS2NSS1
- -85 dBm @ MCS3NSS1
- -82 dBm @ MCS4NSS1
- -78 dBm @ MCS5NSS1
- -76 dBm @ MCS6NSS1
- -75 dBm @ MCS7NSS1
- -70 dBm @ MCS8NSS1
- -69 dBm @ MCS9NSS1
- -90 dBm @ MCS0NSS2
- -90 dBm @ MCS1NSS2
- -87 dBm @ MCS2NSS2
- -83 dBm @ MCS3NSS2
- -80 dBm @ MCS4NSS2
- -76 dBm @ MCS5NSS2
- -74 dBm @ MCS6NSS2
- -73 dBm @ MCS7NSS2
- -67 dBm @ MCS8NSS2
- -66 dBm @ MCS9NSS2
- -88 dBm @ MCS0NSS3
- -88 dBm @ MCS1NSS3
- -85 dBm @ MCS2NSS3
- -81 dBm @ MCS3NSS3
- -78 dBm @ MCS4NSS3
- -74 dBm @ MCS5NSS3
- -72 dBm @ MCS6NSS3
- -71 dBm @ MCS7NSS3
- -64 dBm @ MCS8NSS3
- -63 dBm @ MCS9NSS3
| 5 GHz
802.11ac (VHT80)- -90 dBm @ MCS0NSS1
- -88 dBm @ MCS1NSS1
- -86 dBm @ MCS2NSS1
- -82 dBm @ MCS3NSS1
- -79 dBm @ MCS4NSS1
- -75 dBm @ MCS5NSS1
- -73 dBm @ MCS6NSS1
- -72 dBm @ MCS7NSS1
- -67 dBm @ MCS8NSS1
- -65 dBm @ MCS9NSS1
- -88 dBm @ MCS0NSS2
- -86 dBm @ MCS1NSS2
- -84 dBm @ MCS2NSS2
- -80 dBm @ MCS3NSS2
- -77 dBm @ MCS4NSS2
- -73 dBm @ MCS5NSS2
- -71 dBm @ MCS6NSS2
- -70 dBm @ MCS7NSS2
- -64 dBm @ MCS8NSS2
- -62 dBm @ MCS9NSS2
- -86 dBm @ MCS0NSS3
- -84 dBm @ MCS1NSS3
- -82 dBm @ MCS2NSS3
- -78 dBm @ MCS3NSS3
- -75 dBm @ MCS4NSS3
- -71 dBm @ MCS5NSS3
- -68 dBm @ MCS7NSS3
- -61 dBm @ MCS8NSS3
- -59 dBm @ MCS9NSS3
| - |
